Configuring Device Security
Defining Access Control
Cisco Small Business SFE/SGE Managed Switches Administration Guide 122
4
For each entry, an interface has a bound ACL.
• Interface — Indicates the interface to which the associated ACL is bound.
• ACL Name — Indicates the ACL which is bound to the associated interface.
• Type — Indicates the ACL type to which is bound to the interface.
STEP 2 Modify the relevant fields.
STEP 3 Click Apply. The settings are defined, and the device is updated.
Modifying ACL Binding
STEP 1 Click Security Suite > Access Control > ACL Binding. The ACL Binding Page
opens:
STEP 2 Click the Edit button. The Edit ACL Binding Page opens:
Edit ACL Binding Page
The
Edit ACL Binding Page contains the following fields:
• Interface — Indicates the interface to which the ACL is bound.
• Select MAC Based ACL — Indicates the MAC based ACL which is bound to the
interface.
• Select IPv4 Based ACL — Indicates the IPv4 based ACL which is bound to the
interface.
• Select IPv6 Based ACL — Indicates the IPv6 based ACL which is bound to the
interface.
STEP 3 Define the relevant fields.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
