Configuring Multicast Forwarding
Defining Multicast Forwarding
Cisco Small Business SFE/SGE Managed Switches Administration Guide 245
9
STEP 1 Click Bridging > Multicast > Forward. The Multicast Forward Page opens:
Multicast Forward Page
The
Multicast Forward Page contains the following fields:
• VLAN ID — Displays the VLAN ID.
• Ports — Displays the Multicast Forwarding status of all of the specified
stacking member’s ports.
• LAGs — Displays the Multicast Forwarding status of all of the device’s LAGs.
• Interface — Indicates the port or LAG whose Multicast forwarding
configuration is described.
• Interface Status — Displays the interface status. The options are as follows:
- Static — Attaches the port to the Multicast group as static member.
- Forbidden — Forbidden ports are not included the Multicast group, even
if IGMP snooping designated the port to join a Multicast group.
- Excluded — The port is not part of a Multicast group.
- Dynamic — Attaches the port to the Multicast group as dynamic
member.
Modifying Multicast Forwarding
STEP 2 Click the Edit button. The Edit Multicast Forward All Page opens:

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
