Configuring Device Security
Defining Access Control
Cisco Small Business SFE/SGE Managed Switches Administration Guide 119
4
Modifying IPv6 Based ACL
STEP 1 Click Security Suite >Access Control > IPv6 Based ACL. The
Edit IPv6 Based ACL
Page
opens.
STEP 2 Click the Edit button. The
Edit IP Based ACL Page
opens:
Edit IPv6 Based ACL Page
The Edit IPv6 Based ACL Page contains the following fields:
• ACL Name — Displays the user-defined IPv6 based ACLs.
• Rule Priority — Indicates the rule priority, which determines which rule is
matched to a packet on a first-match basis.
• Protocol — Creates an ACE based on a specific protocol. For a list of available
protocols, see the Protocol field description in the
IPv6 Based ACL Page
above.
• Source Port — Defines the TCP/UDP source port to which the ACE is matched.
This field is active only if 800/6-TCP or 800/17-UDP are selected in the Select
from List drop-down menu. The possible field range is 0 - 65535.
• Destination Port — Defines the TCP/UDP destination port. This field is active
only if 800/6-TCP or 800/17-UDP are selected in the Select from List drop-
down menu. The possible field range is 0 - 65535.
