Viewing Statistics
Viewing Ethernet Statistics
Cisco Small Business SFE/SGE Managed Switches Administration Guide 365
17
• Frame Check Sequence (FCS) Errors — Displays the number of FCS errors
received on the selected interface.
• Single Collision Frames — Displays the number of single collision frames
received on the selected interface.
• Late Collisions — Displays the number of late collision frames received on the
selected interface.
• Oversize Packets — Displays the number of oversized packets (over 1518
octets) received on the interface since the page was last refreshed.
• Internal MAC Receive Errors — Displays the number of internal MAC received
errors on the selected interface
• Received Pause Frames — Displays the number of received paused frames on
the selected interface.
• Transmitted Pause Frames — Displays the number of paused frames
transmitted from the selected interface.
Resetting Etherlike Statistics Counters
STEP 2 Click the Clear Counters button. The interface statistics counters are cleared.
Viewing GVRP Statistics
The GVRP Page contains statistics for GVRP communication on the device.
To view GVRP statistics:

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
