Configuring VLANs
Defining Protocol Groups
Cisco Small Business SFE/SGE Managed Switches Administration Guide 184
6
Add CPE VLAN Mapping Page
The
Add CPE VLAN Mapping Page contains the following fields:
• CPE VLAN — Defines the CPE VLAN which is mapped to the Multicast TV
VLAN.
• Multicast TV VLAN — Defines the Multicast TV VLAN which is mapped to the
CPE VLAN.
STEP 3 Define the mapping.
STEP 4 Click Apply. CPE VLAN Mapping is modified, and the device is updated.
Defining Protocol Groups
The Protocol Group Page contains information defining protocol names and the
VLAN Ethernet type. Interfaces can be classified as a specific protocol based
interface. Protocol Groups are supported in Layer 3 mode.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
