Configuring Ports
Configuring Ports Settings for Layer 2 Enabled Devices
Cisco Small Business SFE/SGE Managed Switches Administration Guide 153
5
- Down — Port is disconnected.
• Port Speed — Displays the current port speed.
• Duplex Mode — Displays the port duplex mode. This field is configurable only
when auto negotiation is disabled, and the port speed is set to 10M or 100M.
This field cannot be configured on LAGs. The possible field values are:
- Full — Indicates that the interface supports transmission between the
device and the client in both directions simultaneously.
- Half — Indicates that the interface supports transmission between the
device and the client in only one direction at a time.
• PVE — Indicates that this port is protected by an uplink, so that the forwarding
decisions are overwritten by those of the port that protects it. PVE is supported
in Layer 2 mode.
• LAG — Defines if the port is part of a Link Aggregation Group (LAG).
STEP 2 To copy the settings from one interface to another, enter the specific interface
numbers in the Copy From Entry Number and To Entry Number(s) fields.
STEP 3 Define the Unit number.
STEP 4 Click Apply. The Port Settings are defined, and the device is updated.
Modifying Port Settings
STEP 1 Click Bridging > Port Management > Port Settings. The Port Settings Page opens:
STEP 2 Define the Unit number.
STEP 3 Click a specific entry’s Edit button. The Edit Port Page opens:

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
