Cisco SGE2000 - Cisco - Gigabit Switch Administration Guide

Configuring IP Information
IP Addressing
Cisco Small Business SFE/SGE Managed Switches Administration Guide 211
7
• UDP Destination Port— Indicate the destination UDP port ID number of the
relayed UDP packets. The following table lists UDP Port allocations.
• Destination Address— The IP interface that receives UDP packet relays. If this
field is 0.0.0.0, UDP packets are discarded. If this field is 255.255.255.255, UDP
packets are flooded to all IP interfaces.
STEP 2 Click the Add button. The Add UDP Relay Page opens:
UDP Port Number Acronym Application
7 Echo Echo
11 SysStat Active User
15 NetStat Netstat
17 Quote Quote of the day
19 CHARGEN Character Generator
20 FTP-data FTP Data
21 FTP FTP
37 Time Time
42 NAMESERVE Host Name Server
43 NICNAME Who is
53 DOMAIN Domain Name Serve
69 FTP Trivial File Transfer
111 SUNRPC Sun Microsystems Rpc
123 NTP Network Time
123 NTP Network Tim
137 NetBiosNameService NT Server to Station Connections
138 NetBiosDatagramServi
ce
NT Server to Station Connections
139 NetBios
SessionServiceNT
Server to Station Connections
161 SNMP Simple Network Management
162 SNMP-trap Simple Network Management
Traps
513 who Unix Rwho Daemon
525 timed Time Daemon
514 syslog System Log

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
