Configuring IP Information
IP Addressing
Cisco Small Business SFE/SGE Managed Switches Administration Guide 208
7
• Interface — Specifies the interface to be associated with this IP configuration.
• IP Address — Defines the currently configured IP address.
• Network Mask — Defines the currently configured IP address mask.
• Prefix Length — Specifies the length of the IPv6 prefix. The range is 5 -128 (64
in the case EUI-64 parameter is used). The
Prefix field is applicable only when
the IPV6 Static IP Address is defined as an Global IPv6 Address.
STEP 3 Define the relevant fields.
STEP 4 Click Apply. The new IP interface configuration is defined, and the device is
updated.
Modifying IP Interface Settings
STEP 1 Click System > System Management > IP Addressing > IP Interface. The IPv4
Interface Page
opens:
STEP 2 Click the Edit button. The Edit IP Interface Page opens:
Edit IP Interface Page
The
Edit IP Interface Page contains the following fields:
• IP Address — Defines the currently configured IP address.
• Network Mask — Defines the currently configured IP address mask.
• Interface — Specifies the interface associated with this IP configuration.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
