Cisco SGE2000 - Cisco - Gigabit Switch Administration Guide

Configuring IP Information
Domain Name System
Cisco Small Business SFE/SGE Managed Switches Administration Guide 225
7
• Enable DNS — Enables translating the DNS names into IP addresses. The
possible field values are:
- Checked — Translates the domains into IP addresses.
- Unchecked — Disables translating domains into IP addresses.
Default Parameters
• Default Domain Name — Specifies the user-defined DNS server name (1 -158
characters).
• Type — Displays the IP address type. The possible field values are:
- Dynamic — The IP address is dynamically created.
- Static — The IP address is a static IP address.
• Remove — Removes DNS servers. The possible field values are:
- Checked — Removes the selected DNS server
- Unchecked — Maintains the current DNS server list.
DNS Server Details
• DNS Server — Displays the DNS server’s IP address, up to four DNS servers
can be defined.
• Active Server — Specifies the DNS server that is currently active.
STEP 2 Click the Add button. The Add DNS Server Page opens:
Add DNS Server Page
The
Add DNS Server Page allows system administrators to define new DNS
servers. The
Add DNS Server Page page contains the following fields.
• Supported IP Format— Select version 6 for IPv6 or version 4 for IPv4.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
