Cisco SGE2000 - Cisco - Gigabit Switch Administration Guide

Defining Address Tables
Defining Dynamic Addresses
Cisco Small Business SFE/SGE Managed Switches Administration Guide 234
8
• Aging Interval — Specifies the amount of time the MAC address remains in the
Dynamic MAC Address table before it is timed out, if no traffic from the source
is detected. The default value is 300 seconds.
• Clear Table — If checked, clears the MAC address table.
Query By
In the Query By section, select the preferred option for sorting the addresses
table:
• Interface — Specifies the interface for which the table is queried. The query
can search for specific ports or LAGs.
• MAC Address — Specifies the MAC address for which the table is queried.
• VLAN ID — Specifies the VLAN ID for which the table is queried.
• Address Table Sort Key — Specifies the means by which the Dynamic MAC
Address Table is sorted. The address table can be sorted by address, VLAN, or
interface.
STEP 2 Define the relevant fields.
STEP 3 Click Query. The Dynamic MAC Address Table is queried, and the results are
displayed.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
