Configuring Device Security
Defining Authentication
Cisco Small Business SFE/SGE Managed Switches Administration Guide 59
4
• Use Default — Uses the default value for the parameter.
STEP 3 Define the relevant fields.
STEP 4 Click Apply. The RADIUS Server is added, and the device is updated.
Modifying RADIUS Server Settings
STEP 1 Click Security Suite > Authentication > RADIUS. The RADIUS Page opens:
STEP 2 Click the Edit button. The Edit RADIUS Server Page opens:
Edit RADIUS Server Page
The
Edit RADIUS Server Page contains the following fields:
• IP Address — Defines the RADIUS Server IP address.
• Priority — Displays the server priority. The possible values are 0-65535, where
1 is the highest value. The RADIUS Server priority is used to configure the
server query order.
• Source IP Address — Defines the source IP address that is used for
communication with RADIUS servers.
• Authentication Port — Displays the authentication port. The authentication port
is used to verify the RADIUS server authentication. The authenticated port
default is 1812.
• Accounting Port — Indicates the port used to send login and logout messages
to the RADIUS server.

Cisco SGE2000 - Cisco - Gigabit Switch Specifications

General

Form Factor	Rack-mountable
Switching Capacity	48 Gbps
Forwarding Rate	35.7 Mpps
Layer	Layer 2
Power Supply	Internal
Management	Web-based, SNMP, CLI
MAC Address Table Size	8000 entries
VLANs	256
Features	Quality of Service (QoS), IGMP snooping, Port mirroring
Dimensions (W x D x H)	440 x 257 x 44 mm (17.3 x 10.1 x 1.73 in)
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20 to 70°C (-4 to 158°F)
Relative Humidity	10% to 90% non-condensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
