Chapter 2 Specifications and System Configuration
2-69
Product ID
0B49
Serial transmission
speed supported
(auto-detection)
9.6 kbps; 19.2 kbps; 31.25 kpbs;45.45 kbps;93.75 kbps; 187.5 kbps; 500 kbps;
1.5 Mbps; 3 Mbps; 6 Mbps; 12 Mbps
Electrical specification
Item
Specifications
Power supply
voltage
5 VDC
Electronical
isolation
500 VAC
Weight
190
g
 AH10PFBS-5A
PROFIBUS-DP port
Interface
DB9 connector
Transmission
method
High-speed RS-485
Transmission cable
Shielded twisted pair cable
Communication
Message type
Cyclic data exchange
Module name
AH10PFBS-5A
GSD file
DELA0AFE.GSD
Product ID
0AFE
Serial transmission
speed supported
(auto-detection)
9.6 kbps; 19.2 kbps; 45.45 (31.25) kbps; 93.75 kbps; 187.5 kbps; 500 kbps; 1.5
Mbps; 3 Mbps; 6 Mbps; 12 Mbps
Electrical specification
Power supply
voltage
5 VDC
Electronical
isolation
500 VAC
Weight
115g
 AH10COPM-5A
CANopen interface
Item
Specifications
Transmission
method
CAN
Connector
Removable connector (5.08 mm)
Communication
cable
It is suggested that users should use the Delta standard cables UC-DN01Z-01A
and UC-DN01Z-02A.
The communication cable used should be away from the power cable used,
and the shielded cables used should be connected to the ground.
CANopen communication
Item
Specifications
Message type
PDO, SDO, SYNC, EMC Y, NMT
Transmission speed
10 kbps, 20 kbps, 50 kbps, 125 kbps, 250 kbps, 500 kbps, 800 kbps, 1 Mbps
Electrical specifications
Item
Specifications
Supply voltage
A CPU module supplies 24 VDC (-15%~20%) power through an internal bus.
Electronical isolation
500 VAC
Weight
150g
