2.7 6BSpecifications for Analog Input/Output Modules
2.7.1 27BGeneral Specifications
 AH04AD-5A/AH08AD-5A/AH08AD-5B/AH08AD-5C
Electrical specifications
Module name
AH04AD-5A
AH08AD-5A
AH08AD-5B
AH08AD-5C
Number of inputs
4
8
8
8
Analog-to-digital
conversion
Voltage input/
Current input
Voltage input/
Current input
Voltage input Current input
Supply voltage
24 VDC (20.4 VDC~28.8 VDC) (-15%~+20%)
Connector type
Removable terminal block
Conversion time
150 μs/channel
Isolation
An analog circuit is isolated from a digital circuit by a digital
integrated circuit/an
optocoupler, but the analog channels are not isolated from one another.
Isolation between a digital circuit and a ground: 500 VDC
Isolation between an analog circuit and a ground: 500 VDC
Isolation between an analog circuit and a digital circuit: 500 VDC
Isolation between the 24 VDC and a ground: 500 VDC
Weight
200g
Functional specifications
Analog-to-digital
conversion
Voltage input
Rated input range
-10 V~10 V
0 V~10 V
±5 V
0 V~5 V
1 V~5 V
Hardware input
range
-10.1 V~10.1 V -0.1 V~10.1 V -5.05 V~5.05 V -0.05 V~5.05 V 0.95 V~5.05 V
Fiducial error
(Room
temperature)
±0.1%
Fiducial error
(Full temperature
range)
±0.45%
Linearity error
(Room
temperature)
±0.07%
Linearity error
(Full temperature
range)
±0.12%
Hardware
resolution
16 bits
Input impedance
>1MΩ
Absolute input
range
±15 V
Analog-to-digital
conversion
Current input
Rated input range
±20 mA
0 mA~20 mA
4 mA~20 mA
Hardware input
range
-20.2 mA~20.2 mA -0.2 mA~20.2 mA 3.8 mA~20.2 mA
Fiducial error
(Room
temperature)
±0.1%
Fiducial error
(Full temperature
range)
±0.2%
