4.7.15 Wiring AH32AN02T-5B
Output type
Transistor-T (sinking)
Voltage specifications
12~24 VDC, 0.1 A
Wiring the external terminal module UB-10-OT32B:
Output type
Transistor-T (sinking)
Voltage specifications
12~24 VDC, 0.1 A
