Delta AH500 - 6.5.7 Basic Editing - Inserting an Applied Instruction

AH500 Hardware and Operation Manual
6-20
6.5.7 Basic Editing
-
Inserting an Applied Instruction
Put network 6 under network 5, and then write the program shown below. Users can insert an applied
instruction in one of the three ways described below.
 Method 1
Click the position where an instruction will be inserted, type the instruction (INC in this example), and
press Enter on the keyboard.
 Method 2
Unfold the APIs section in the project management area, find the instruction type, and unfold the
instruction type section.
Select the instruction (INC in this example) which will be inserted, and then drag it to the position where it
will be inserted.
