Delta AH500 Hardware Operation Manual

AH500 Hardware and Operation Manual
6-14
6.5.3 Basic Editing
-
Inserting a Network and Typing an Instruction
After on the toolbar is clicked, a network will be under the network selected. After on the toolbar is
clicked, a network will be put above the network selected. In this example, a network is under network 1.
A contact and a coil can be created not only by clicking and on the toolbar, but also by typing
instructions.
(1) Click the line in network 2.
(2) Type the IL instruction “LD M0”. (The instruction is case-insensitive.) As soon as the IL instruction is
typed, a box which can be edited appears. After the typing of the IL instruction is complete, users can
press Enter on the keyboard or click OK at the right side of the box.
