Delta AH500 Hardware Operation Manual

Chapter 4 Installing Hardware and Wiring
4-99
4. External terminal module for AH15PM-5A: UB-10-IO34C
1
st
from the
upper left
Y0.11 Y0.9 COM Y0.7- Y0.6- Y0.5- Y0.4- Y0.3- Y0.2- Y0.1- Y0.0- X1.5 X1.3 X1.1
15
th
from the
upper left
X0.15 X0.13 X0.11 X0.9- X0.8- X0.7 X0.5 X0.3- X0.2- X0.1- X0.0- 24G 24G FE
1
st
from the
lower left
Y0.10 Y0.8
Y0.7+
Y0.6+ Y0.5+ Y0.4+
Y0.3+
Y0.2+ Y0.1+ Y0.0+ S/S Y1.4 Y1.2 Y1.0
15
th
from the
lower left
X0.14 X0.12
X0.10
X0.9+ X0.8+ X0.6 X0.4 X0.3+ X0.2+ X0.1+
X0.0+
N/C 24V 24V
4.13.3 Wiring AH02HC-5A and AH04HC-5A
 External devices for AH02HC-5A
02HC
ERROR
RUN
C0
Y0.8
Y0.9
C1
X0.8 +
X0.8
-
X0.9 +
X0.9
-
X0.10+
X0.10
-
X0.11+
X0.11
-
X0.0 +
X0.0
-
X0.1
-
X0.1 +
USB
