Delta AH500 - 4.9.6 Wiring AH08 DA-5 C

AH500 Hardware and Operation Manual
4-72
4.9.6 Wiring AH08DA-5C
AC mo tor d rive,
recorder,
propo rtioning valve
IO0
AG
CH0
0mA~20mA
CH0
AG
ZP
UP
24VDC
DC/DC
Converter
+15V
-15V
AG
SG
CH7
0mA~20mA
CH7
AG
IO7
AG
*2
SG
*2
SG
*3
Current output
Shielded cable *1
AC mo tor d rive,
recorder,
propo rtioning valve
Current output
Shielded cable *1
*1. Please the shielded cables isolate the analog output signal cable from other power cables.
*2. Please connect the shielded cables to the terminal SG.
*3. Once AH08DA-5C is installed on a backplane, the terminal SG on AH08DA-5C and the terminal on
the backplane will be short-circuited. Please connect the terminal on the backplane to the ground
terminal
.
