AH500 Hardware and Operation Manual
4-60
4.8.1.5 Three-wire Switch
Sinking
Sourcing
Three-wire switch
S/S
X0.0
I/O
24VDC
Internal
circuit
S/S
X0.0
I
/O
24VDC
Internal
circuit
Three-wire switch
