AH500 Hardware and Operation Manual
4-32
4.7 Wiring Digital Input/Output Modules
The wiring of digital input/output modules is illustrated simply in this section. The simplistic wiring diagrams
below also illustrate how the power supplies are connected to S/S, UP, ZP and COM. If users want to get more
information about the wiring of digital input/output terminals, they can refer to section 4.8 in this manual.
4.7.1 Wiring AH16AM10N-5A
Input form
Direct current (sinking or sourcing)
Input current
24 VDC, 5 mA
7
10
12
11
9
8
6
5
4
3
2
15
14
6
7
13
S/S
24VDC
5mA
1
0
16AM10N
0 2 31
5
4
S/S
98 1510 11 12 13 14
