Delta AH500 - 4.5.4 Power Consumption

AH500 Hardware and Operation Manual
4-26
4.5.4 Power Consumption
Classification
Model name Internal power consumption
External power
consumption
CPU module
AHCPU500-RS2 2W -
AHCPU501-RS2 2.9W -
AHCPU510-RS2 2W -
AHCPU511-RS2 2.9W -
AHCPU520-RS2 2W -
AHCPU521-RS2 2.9W -
AHCPU530-RS2 2W -
AHCPU531-RS2 2.9W -
AHCPU500-EN 2W -
AHCPU501-EN 2.9W -
AHCPU510-EN 2W -
AHCPU511-EN 2.9W -
AHCPU520-EN 2W -
AHCPU521-EN 2.9W
AHCPU530-EN 2W -
AHCPU531-EN 2.9W -
AHCPU521-DNP 2.9W -
AHCPU560-EN2 4.5W -
Main
backplane
AHBP04M1-5A 10mW -
AHBP06M1-5A 10mW -
AHBP08M1-5A 10mW -
AHBP12M1-5A 10mW -
Extension
backplane
AHBP06E1-5A 1.41W -
AHBP08E1-5A 1.41W -
Redundant
main
backplane
AHBP04MR1-5A 0.2W -
AHBP06MR1-5A 0.2W -
AHBP08MR1-5A 0.2W -
Redundant
extension
backplane
AHBP06ER1-5A 1.1W -
AHBP08ER1-5A 1.1W -
Digital I/O
module
AH16AM10N-5A 0.1W 1.9W
AH16AM30N-5A 0.1W -
AH16AN01P-5A 0.2W 0.4W
AH16AN01R-5A 2.1W -
AH16AN01S-5A 0.6W -
