Chapter 11 Convenient Functions
11-47
Multiple nodes
The data demanding setting related to all the nodes, and the start modes of all the nodes are downloaded.
Before the users download the related parameters, they have to make sure that all the PLCs and all the
modules are connected to an Ethernet network, and can connect to NWCONFIG through Ethernet. The
connection type that the driver selected in the Driver Name drop-down list box in the Select a Driver
window uses must be Ethernet, otherwise the related parameters can not be downloaded. Please refer to
section 20.1.3 from ISPSoft User Manual for more information.
Method 1
Click the PLC menu, point to Transfer, and click Download (Multiple PLCs). The users can also
download the related parameters by clicking
on the toolbar.
Method 2
Select All Nodes on the node list, right-click All Nodes, and click Download (Multiple PLCs) on the
context menu.
Additional remark
If the parameters set include a node which does not demand any data, the node will not demand any data
through the network specified after the parameters are downloaded to multiple nodes.
The node does not
demand any data.
