AH500 Hardware and Operation Manual
11-94
Set up the sample period and trigger setting.
After setting up the parameters, click on the icon toolbar to have the system in the online mode. Then
click
to download the settings to the PLC.
After the sample parameter settings in the data tracer are completed and downloaded, any of the
following three modes on the icon toolbar can be used for watching curves in the online mode.
Click on the icon toolbar to export the data to your computer for future use.
