Chapter 2 Specifications and System Configuration
2-43
4. External terminal modules for AH32AN02P-5B
UB-10-OR32B
215
87
39.
4
Unit: mm
UB-10-OT32B
113
87
50.8
Unit: mm
Latch connector, I/O extension cable, and external terminal module
1. I/O extension cable UC-ET010-24A
100
1 2
1 2
39 4039 40
Unit: cm
2. External terminal module for AH32AM10N-5C/AH64AM10N-5C: UB-10-ID32A
113
87
53.6
Unit: mm
