4. TIS transponder from SV-XPNDR-261/262 / Garmin GTX 330 (when in an active TIS
coverage area).
5. Flarm device.
6. Zaon device.
7. SV-ADSB-470/472 with an incomplete traffic portrait (ADS-B NO RADAR): SkyView will
annunciate “No Radar” traffic when it has ADS-B reception capability, but that ADS-B
reception does not include either ADS-B ground station coverage or radar targets
included within those ground-based ADS-B traffic reports. Thus, the ADS-B ground
station is not able to convey a full traffic picture and cannot make you aware of all
possible detectable traffic.
Traffic Alert
The alert in Figure 125 below is shown on both the PFD Page (near the top of the IAS tape) and
the Map Page (lower right) whenever there are Traffic Advisory Targets present.
Figure 125 – Traffic Alert
Button
On the Main Menu, the (Direct-To) button brings up the Info page when it is pushed when
nothing is selected. If there is an active flight plan, the current waypoint will appear on the
resulting info page. also instantly starts navigation to an airport, navaid, or other waypoint
when one is selected in the Nearest, Info, Flight Plan, or Map Pointer pages. See the Moving
Map section below for more information.
NRST Button
On the Main Menu, the NRST (Nearest) button brings up a window that displays the nearest
airports, navaids, and user waypoints. Once the Nearest list is displayed, the FILTER button can
be used to filter out airports that are less useful to you (based on length, surface type, and
usage). If the FILTER button is highlighted the list is filtered. Press FILTER again to show all
airports (button is black when filter is off).
FILTER options can be configured in MAP SETUP > NEAREST LIST OPTIONS (press-and-hold
Buttons 7+8, then selecting MAP SETUP > NEAREST LIST OPTIONS). Note that some airports may
be completely screened out of the NRST list, regardless of the FILTER settings, if they are set to
OFF in the MAP MENU > MAP ITEMS options. See the Moving Map section below for more
information.
