SkyView HDX Display Operation

3-2 SkyView HDX Pilot’s User Guide – Revision B

• The largest, central portion of the screen presents PFD, Engine, and Moving Map data,

configuration information, menu and feature control pages, and many system

messages. Its layout is user configurable. Detailed instructions on how to configure the

layout of your screen are presented in a later section of this manual.

• Knob and button labels are arranged across the bottom of the display in a menu bar.

Knob and button functionality is contextual based on what is on screen, and these labels

show the user the current function. For example, the (MAP) label above the right knob

in Figure 1 – SkyView HDX Display Front Bezel Layout (SV-HDX1100 shown) shows that

manipulating that knob will affect what the user can see on the Moving Map page.

Throughout this manual, the buttons are referred to by their relative numbered

position, counting from left to right. Button 1 is the left-most button, and Button 8

is the right-most button.

The bottom menu bar initially displayed once the system is fully powered on is

referred to as the Main Menu.

Each SkyView HDX display has an integrated light-detecting sensor in the front bezel. This light

sensor can be used for automatic backlight level management. Reference the SkyView Classic /

SE / HDX System Installation Guide for instructions on how to configure the display for

automatic backlight level management.

Basic Display Operation Procedures

This subsection covers basic operation procedures for displays. Detailed instructions for various

setup menus and individual menu items are described in the SkyView Classic / SE / HDX System

Installation Guide.

How to Turn the System On or Off

The following table summarizes the procedures for toggling SkyView system power states.
