SkyView HDX System Overview
2-8 SkyView HDX Pilot’s User Guide – Revision B
External Controls, Indicators, Jacks, etc.
The primary harness for each SkyView HDX display provides inputs or outputs for external
buttons, switches, indicators, jacks, etc. Some of these are required (such as Servo Disconnect /
CWS), while others provide optional additional functionality.
As part of your familiarization with your SkyView HDX system, you should identify these
additional controls on your panel or elsewhere in your cabin, and how they interact with your
SkyView HDX system. For additional detail, please reference the SkyView Classic / SE / HDX
System Installation Guide, Appendix K: Switches, etc. External to SkyView Units.
This list does not reference power control breakers, switches, or semi-automated power
control systems such as ADVANCED Control Module or VP-X.
• Autopilot (Servos):
o Servo Disconnect / Control Wheel Steering (CWS) Button
• Heated AOA/Pitot Probe:
o Heated Pitot Off / Failed Warning Indicator
• SV-AP-PANEL (Electric Trim):
o (These controls may be integrated into a “Hat Switch”)
o Pilot Trim Controls: Up, Down, Left, Right
o Copilot Trim Controls: Up, Down, Left, Right
• SV-COM-425 / X83:
o Copilot Headset Jacks
o Copilot Push-To-Talk (PTT) Button (Likely integrated into the stick)
o Pilot Headset Jacks
o Copilot Push-To-Talk (PTT) Button (Likely integrated into the stick)
o Active / Standby Frequency Flip/Flop Button
• SV-D600 / SV-D700 / SV-D900 / SV-D1000 / SV-D1000T / SV-HDX800 / SV-HDX1100:
o Autopilot GO AROUND Button
o Autopilot SV-BUTTON-LEVEL (LEVEL Button)
o SV-KNOB-DIMMER (Dim Control Knob)
o USB Jacks (one per display)
• SV-EMS-220 / 221:
o Master EMS Warning Indicator
• SV-INTERCOM-2S:
o Copilot Push-To-Talk (PTT) Button (Likely integrated into the stick)
o Copilot Headset Jacks
o Music In Jack
o Pilot Push-To-Talk (PTT) Button (Likely integrated into the stick)
o Pilot Headset Jacks
o Radio Select (Transmit) Switch
• SV-XPNDR-261/262:
