SkyView HDX System Overview
SkyView HDX Pilot’s User Guide – Revision B 2-7
Currently the UAT Band is only used in the US.
Com Radios – SV-COM-C25 and SV-COM-X83
The SV-COM-C25 is an integrated VHF Com Radio for SkyView consisting of two modules: the
SV-COM-PANEL, and the SV-COM-425. The SV-COM-C25 has 25 kHz channel spacing and is
intended primarily for aircraft operating in the US. The SV-COM-X83 is an integrated VHF Com
Radio consisting of two modules, the SV-COM-PANEL, and the SV-COM-T8. The SV-COM-X83
has 8.33 kHz channel spacing required for European pilots. Both the SV-COM-C25 and SV-COM-
X83 can tune frequencies by querying an aviation database installed in SkyView HDX.
Intercom – SV-INTERCOM-2S
The SV-INTERCOM-2S is a two-place stereo intercom that is designed to pair perfectly with your
SkyView System and SkyView Com Radio. It has stereo inputs for SkyView audio alerts, stereo
music, and multiple other mono muting and non-muting inputs.
Knob Panel – SV-KNOB-PANEL
The SV-KNOB-PANEL is an optional panel-mounted module for SkyView. This control panel has
three knobs dedicated to the most common SkyView bug functions – ALT, BARO, and HDG/TRK.
This module is particularly useful in systems with the SkyView autopilot installed. Note that
these bugs can also be adjusted from the SkyView HDX display.
SkyView Video Input Adapter
The optional SkyView Video Input Adapter enables the display of a video signal (must be S-
Video or Composite) on your SkyView HDX display in a 50% window (replaces the non-PRIMARY
CONTENT window). If a 100% window is selected, when a video signal is displayed, the 100%
window will be reduced to a 50% window while the video signal is displayed. The SkyView
Video Input Adapter must be inserted into one of the two USB plugs on the back of the SkyView
HDX display during system power-on and while operating.
SkyView Wi-Fi Adapter
The optional SkyView Wi-Fi Adapter allows supported devices, such as Apple iPhones and iPads,
with supported apps, such as ForeFlight, to exchange data with SkyView HDX. For example, you
can compose a flight plan (or, multiple flight plans) in ForeFlight, and after you get to your
plane, ForeFlight can send a flight plan to SkyView. The SkyView Wi-Fi Adapter must be inserted
into one of the two USB plugs on the back of the SkyView HDX display during system power-on
and while operating. For proper function, each display in a SkyView HDX system must be
equipped with a Wi-Fi adapter.
For current devices and apps compatible with SkyView HDX / SkyView Wi-Fi Adapter, see
http://www.dynonavionics.com/skyview-wifi-adapter.php.
