Autopilot Operation
8-20 SkyView HDX Pilot’s User Guide – Revision B
Control
Autopilot Servos
Flight Director
Lateral Mode
Vertical
Mode
AP
Engaged
On
ROLL
VS
FD
Not Engaged
On
ROLL
VS
HDG
Not Engaged
On
HDG
VS
TRK
Not Engaged
On
TRK
VS
NAV
Not Engaged
On
NAV
VS
VS
Not Engaged
On
ROLL
VS
IAS
Not Engaged
On
ROLL
IAS
ALT
Not Engaged
On
ROLL
ALT
VNAV
Not Engaged
On
ROLL
ALT->VNAV
LEVEL
Engaged
On
ROLL (0
degrees)
VS (0
ft./min)
Disconnect
Hold To engage
Engaged
On
ROLL
VS
Figure 226 – Expert Autopilot Button Press Results
Disengaging the Autopilot
When engaged:
• Press the autopilot disconnect switch once to disengage the servos while leaving the
flight director active with all active and armed modes unchanged. Press the autopilot
disconnect again within 1 second to turn the flight director off (regardless whether the
autopilot was engaged).
• Press the AP button to disengage the servos while leaving the flight director active with
all active and armed modes unchanged. Flight director guidance continues.
o Using the AP button to disconnect is useful for times when you want to will want
to re-engage the autopilot with the same modes that you had used previously.
• Press the FD button when the servos are disengaged to turn off the flight director and
remove all active and armed modes and indications. This effectively “resets” the
autopilot.
• Pressing the button for any active mode (except an external LEVEL button or SV-AP-
PANEL LEVEL button) turns off that mode and any armed mode for the axis, turns off the
flight director and disengages the servo for the axis.
• Pressing the button for any armed mode disarms that mode.
Expert Autopilot Roll Modes
The following table summarizes the different autopilot modes of operation for the roll axis.
Mode
Annunciation
Description
Control
Roll Hold
ROLL
Holds the current aircraft roll angle.
Default mode or
ROLL HOLD button
