MAP and VFR GPS Navigator Operation
5-30 SkyView HDX Pilot’s User Guide – Revision B
• TOPOG – Pressing the TERRAIN icon button displays high resolution terrain and
basemap with digital aviation and obstacle data. The aviation and obstacle data will vary
depending on the various databases installed (Dynon Avionics / FAA, or others).
• VFR – Pressing the VFR button displays georeferenced VFR enroute charts
(sectionals/world area/terminal area charts in the US). The VFR icon is only displayed
when that data is available on a USB flash drive plugged into the SkyView HDX display.
The label of this icon may change when using data for regions outside the US.
• IFR LOW – Pressing the IFR LOW button displays georeferenced IFR low altitude enroute
charts. The IFR LOW icon is only displayed when that data is available on a USB flash
drive plugged into the SkyView HDX display.
• IFR HIGH – Pressing the IFR HIGH button displays georeferenced IFR high altitude
enroute charts. The IFR HIGH icon is only displayed when that data is available on a USB
flash drive plugged into the SkyView HDX display.
WEATHER (In MAP CONTROLS)
Pressing the WEATHER icon opens the WEATHER OPTIONS Menu, which allows you to select
several weather-related options. The WEATHER OPTIONS menu is discussed in detail in a later
section of this manual.
USER WAYPOINTS (In MAP CONTROLS)
Pressing the USER WAYPOINTS icon opens the USER WAYPOINTS page. That page presents a
list of user-created waypoints existing in SkyView, together with button controls on the bottom
of the page for creating, editing and deleting user waypoints and for importing and exporting
user waypoints to/from a USB stick. Managing user waypoints is discussed in detail in a later
section of this manual.
Navigation and Flight Planning
SkyView HDX’s Moving Map course information can be displayed on the SkyView
PFD’s HSI display when it is selected and navigating to an active waypoint. It is
always labeled SKYVIEW in the HSI and in the Flight Planning window.
Navigation Methods
SkyView supports two internal types of navigation. Direct-To navigation lets you quickly fly
“directly to” a waypoint by pushing the button whenever it is displayed. Additionally,
SkyView offers robust Flight Planning that allows navigation to a sequence of one or more
waypoints. Both of these methods are covered in the following sections.
Find an Airport or Navaid by Identifier
To find an airport or navaid, press INFO (Button 4) on the Main Menu bottom bar. A window
like the one seen in Figure 127 will be displayed.
