SkyView HDX Display Operation
3-6 SkyView HDX Pilot’s User Guide – Revision B
Change Map scale
Rotate knob (labeled MAP)
Scroll vertically through a list
(on text menus or data pages)
Rotate knob (labeled CURSR)
Scroll horizontally across tabs on the
NRST or INFO page
Push-Hold-and-Rotate knob (labeled CURSR)
Choose items on icon-based menu and
feature control pages:
• Activate and/or move cursor
• Rotate knob (labeled CURSR)
• Select menu or feature icons
• Push knob (labeled CURSR)
Navigate text menus:
(ie: In-flight Setup; System Setup)
• Move cursor to desired item
• Rotate knob (labeled CURSR)
• Select menu item:
• Push knob (labeled CURSR)
• Retreat to prior menu:
• Push-and-hold knob (for at least ½ second)
Edit a data field:
(ie: Airport ID on INFO page)
• Begin editing:
• Push knob (labeled CURSR)
• Adjust selected character
• Rotate knob (labeled CURSR)
• Advance to next character
• Push knob (labeled CURSR)
• Retreat to prior character
• Push-and-hold knob for at least ½ second
• End editing:
• Touch another field to edit, or select any of
the available action items on the page (eg:
EXIT (menu or icon), ACCEPT, RETURN icon)
Table 4 – Knob Operation Summary
Main Menu (Buttons) Navigation
After the display turns on you will see a screen like the one shown below.
