SkyView HDX Display Operation
3-26 SkyView HDX Pilot’s User Guide – Revision B
Button(s)
Action
Pre-condition
Result
N/A
Apply power to
display(s)
N/A
Display powers ON
N/A
Disconnect power to
display(s); turn off
avionics circuit
breaker or power
switch
SV-BAT-320 Backup
Battery Installed,
aircraft is in flight:
Warning is displayed:
“POWERING DOWN IN 30
SECONDS”.
Press Button 8 to acknowledge
Display remains powered ON
(for duration of SV-BAT-320)
SV-BAT-320 Backup
Battery Installed,
aircraft is stationary:
Warning is displayed:
“POWERING DOWN IN 30
SECONDS”.
Within 30 seconds, press
Button 8 to acknowledge.
If Button 8 is not pushed within
30 Display remains powered
ON (for duration of SV-BAT-
320)
SV-BAT-320 Backup
Battery Not Installed
Display powers off
1
Push for approx. 2
seconds
If display is OFF
powers display ON.
If display is on
powers display OFF.
1+2+5
Push simultaneously
and release
Reboots display; equivalent to
powering off and on again.
2+7
Push simultaneously
and release
If USB flash drive is
plugged in
records “screenshot” file to the
USB flash drive. Message:
SCREENSHOT SAVED TO USB
DRIVE
If no USB flash drive
plugged in
Message: SCREENSHOT
MISSING USB DRIVE
7+8
Push simultaneously
for approx. 2
seconds
If in flight
opens
IN FLIGHT SETUP MENU
If stationary
opens
SETUP MENU
Table 6 – Non-Menu Operations (“Hidden” Functions)
