Port Priority Configuration
Configuring Quality of Service (QoS)
Matrix E1 Series (1G694-13) Configuration Guide 7-11
7.2.3.2 set port qos wrr
Use this command to set the weighted round robin transmission queue weights for a particular port
type.
set port qos wrr port_type que0_weight que1_weight que2_weight que3_weight
Syntax Description
Command Defaults
None.
Command Mode
Read-Write.
Example
This example shows how to set weighted queues on the 1-Gigabit Ethernet ports. In this example
the queues 0, 1, 2, and 3 are being set to 10, 20, 30, and 40 percent, respectively.
port_type Specifies the port type on which to set QoS weighted
queues. 1G = Gigabit Ethernet. 10G = 10-Gigabit
Ethernet.
que0_weight Specifies a percentage weight (1 through 100, with 25 as
the default) for queue 0.
que1_weight Specifies a percentage weight (1 through 100, with 25 as
the default) for queue 1.
que2_weight Specifies a percentage weight (1 through 100, with 25 as
the default) for queue 2.
que3_weight Specifies a percentage weight (1 through 100, with 25 as
the default) for queue 3.
NOTE: The total percentage of transmit queue settings que0_weight through
que3_weight must add up to 100%, otherwise the command is illegal. que3_weight
must be greater than or equal to que2_weight which, in turn must be greater than or
equal to que1_weight which, in turn, must be greater than or equal to que0_weight.
Matrix>set port qos wrr 1G 10 20 30 40
QOS weighted round robin set for 1G ports.
