Port Configuration
Overview: Port Mirroring
4-26 Matrix E1 Series (1G694-13) Configuration Guide
4.2.7 Overview: Port Mirroring
The Matrix E1 allows you to mirror the traffic being switched on a port for the purposes of
network traffic analysis and connection assurance. When port mirroring is enabled, one port
becomes a monitor port for another port within the switch. When configuring port mirroring on
this device, note that
• Only one mirror is allowed per device;
• Only one mirroring session is allowed at a time;
• Traffic mirrored includes both received and transmitted packets;
• Unknown protocol packets and broadcast packets can be forwarded out the monitor port when
mirroring is enabled.
For details on how to specify port designation in the CLI syntax, refer to Section 4.1.2.
4.2.8 Port Mirroring Commands
Purpose
To display or set a source and target port for port mirroring on the device.
Commands
The commands needed to configure port mirroring are listed below and described in the associated
section as shown.
• show port mirroring (Section 4.2.8.1)
• set port mirroring (Section 4.2.8.2)
CAUTION: Port mirroring configuration should be performed only by personnel who are
knowledgeable about the effects of port mirroring and its impact on network operation.
