Startup and General Configuration
Downloading a Firmware Image
3-24 Matrix E1 Series (1G694-13) Configuration Guide
5. Send the file using the XMODEM protocol from your computer application (the procedure
varies depending upon the application used).
6. When the XMODEM procedure finishes, the following messages are displayed:
7. Change your baud rate back to 9600 and press ENTER. The new image will be loaded and
started.
3.2.3.2 Downloading via TFTP
To perform a TFTP download, you must first set the device’s IP address (as detailed in
Section 3.2.2.11). You then use the dload command to enter the IP address of the TFTP server and
the name of the image file.
dload
Use this command to download a new firmware image from a TFTP server to the device.
dload ip_address filename [noreboot]
Syntax Description
Command Defaults
If noreboot is not entered, the device will reboot automatically using the new
image.
Performing checksum of received image ............... PASSED
Programming primary functional image to flash ....... PASSED
Programming secondary functional image to flash ..... PASSED
ip_address Specifies the address of the TFTP server from which the
new image file will be downloaded.
filename Specifies the TFTP server path and file name of the new
image.
noreboot (Optional) Specifies that the device will not reboot after
completing the download of an image file. The device
will continue using the existing firmware image and will
store the new image in FLASH memory. The next time
the device is reset or powered-up, it will boot from
FLASH memory using the new image.
