Enterasys Matrix E1 1G694-13 User Manual

Startup and General Configuration
Setting Basic System Information
3-22 Matrix E1 Series (1G694-13) Configuration Guide
3.2.2.11 set ip address
Use this command to set the local host IP address and subnet mask.
set ip address ip_addr [ip_mask]
Syntax Description
Command Defaults
If not specified, ip_mask will be set to 255.255.0.0.
Command Mode
Read-Write.
Example
This example shows how to set the host port IP address to
172.29.78.111:
ip_addr Specifies the IP address to be set as the local host.
ip_mask (Optional) Specifies the IP mask of the local host.
Matrix>set ip address 172.29.78.111 255.255.0.0
Local IP address set.
System mask set.
