Matrix E1 Series (1G694-13) Configuration Guide 4-1
4
Port Configuration
This chapter describes the Port Configuration set of commands and how to use them.
4.1 PORT CONFIGURATION SUMMARY
The Matrix E1 1G694-13 features a fixed front panel of twelve 1-Gigabit Ethernet ports and an
optional expansion module slot with one 10-Gigabit Ethernet uplink port.
1-Gigabit Ethernet Ports
The 1-Gigabit Ethernet ports consist of
• eight fixed MT-RJ style ports that are 1000BASE-SX compliant, and
• four port slots that support optional hot-swappable Mini-GBICs.
As of the printing of this manual, there were three Mini-GBIC models available: two that comply
with standard 1000BASE-SX; one that complies with 1000BASE-LX.
10-Gigabit Ethernet Port
The 10-Gigabit Ethernet port is an expansion slot for a 10-Gigabit Ethernet Expansion Module.
Depending on the Ethernet Expansion Module installed, the uplink can be via different connectors
and media that support 10-Gigabit Ethernet operation.
At the time that this manual was printed, there were two Ethernet Expansion Module models
available: ZPIM1-01 and ZPIM-06. Table 4-1 lists the standards these modules comply with and
their physical connection types. Refer to the Matrix E1 1G694-13 Installation Guide for cable
specifics.
