Setup Requirements
Connecting to a Modem
2-6 Matrix E1 Series (1G694-13) Configuration Guide
Figure 2-3 Connecting to a Modem
➀
RJ45 Modem Port
➂
RJ45-to-DB25 Modem Adapter
➄
RJ45 Console Port
➁
Modem
➃
UTP Cable with RJ45 Connectors
1
Reset
Console
CPUPWR
Ä
3712_19
1G694-13
Á
Â
Ã
À
