FS TAP Series User Manual

TAP Series Switch Command Line Reference
66
first-fragment
Match packets with first fragment
non-first-fragment
Match packets with non first fragment
non-fragment
Match packets with non fragment
non-or-first-fragment
Match packets with non first fragment
small-fragment
Match packets with small fragment
any-fragment
Match packets with any fragment
options
Match packets with IP options
vlan ( VLAN_ID VLAN_WILD | any )
Specify the outer vlan id of the acl rule.
The valid range for vlan id is 0-4095.
The valid range for vlan id wildcard bits is 0x0-
0xFFF.
Vlan id and wildcard bits both have 12bits, if a
bit in wildcard is 0 means this bit needs to
check, otherwise this bit should be ignored.
Parameter
“
any
”
indicates packets with any
outer vlan id can match this rule.
inner-vlan ( VLAN_ID VLAN_WILD | any )
Specify the inner vlan id of the acl rule.
The valid range for vlan id is 0-4095.
The valid range for vlan id wildcard bits is 0x0-
0xFFF.
Vlan id and wildcard bits both have 12bits, if a
bit in wildcard is 0 means this bit needs to
check, otherwise this bit should be ignored.
Parameter
“
any
”
indicates packets with any
inner vlan id can match this rule.
cos COS_ID
Specify the outer CoS value of the acl rule.
CoS = Class of Service.
The valid range of Cos is 0 to 7.
inner-cos COS_ID
Specify the inner CoS value of the acl rule.
CoS = Class of Service.
The valid range of Cos is 0 to 7.
ether-type ( ETHER_TYPE_VALUE
ETHER_TYPE_WILD_VALUE | any )
Specify the ether-type of the acl rule.
The valid range for ether-type is 0x600-0xFFFF.
The valid range for wildcard bits is 0x600-
0xFFFF.
Ether-type value and wildcard bits both have
16bits, if a bit in wildcard is 0 means this bit
needs to check, otherwise this bit should be
ignored.
Parameter “any” indicates packets with any
ethertype value can match this rule.
src-mac ( ACL_MAC_ADDR
ACL_MAC_ADDR_WILD | any | host
Specify the source mac address in
HHHH.HHHH.HHHH format.
