TAP Series Switch Command Line Reference
Examples
This example shows how to delete an inner-match filter with sequence number 10 from im1:
Switch(config-inner-match-im1)# no sequence-num 10
Related Commands
show inner-match
match
Use this command to set matching rules for the inner-match filter.
Command Syntax
(sequence-num MATCH_SEQ_NUM|) match ( PROTOCOL_NUM| any | tcp (src-port (range
L4_PORT_NUM L4_PORT_NUM | eq L4_PORT_NUM | gt L4_PORT_NUM | lt L4_PORT_NUM
| any) | dst-port (range L4_PORT_NUM L4_PORT_NUM | eq L4_PORT_NUM | gt
L4_PORT_NUM | lt L4_PORT_NUM | any) |) (tcp-code (match-all | match any) (ack | fin |
psh | rst | syn | urg |) |) | udp (src-port (range L4_PORT_NUM1 L4_PORT_NUM2 | eq
L4_PORT_NUM | gt L4_PORT_NUM | lt L4_PORT_NUM | any ) | dst-port (range
L4_PORT_NUM1 L4_PORT_NUM2 | eq L4_PORT_NUM | gt L4_PORT_NUM | lt
L4_PORT_NUM | any) | icmp | igmp ) (src-ip ( IP_ADDR IP_ADDR_WILD | host IP_ADDR |any)
| src-ipv6 ( IPv6_ADDR IPv6_ADDR_WILD | host IPv6_ADDR |any)) (dst-ip ( IP_ADDR
IP_ADDR_WILD | host IP_ADDR |any) | dst-ipv6 ( IPv6_ADDR IPv6_ADDR_WILD | host
IPv6_ADDR |any)) (flow-label ( FLOW_LABEL LABEL_WILD |any)) (dscp DSCP_VALUE | ip-
precedence PRECEDENCE_VALUE|) ( first-fragment| non-first-fragment| non-fragment|
non-or-first-fragment| small-fragment | any-fragment|) (options|) (vlan (VLAN_ID
VLAN_ID_WILD | any)|) (inner-vlan (VLAN_ID VLAN_ID_WILD |any)|) (cos COS_ID|) (inner-
cos COS_ID|) (ether-type ( ETHER_TYPE_VALUE ETHER_TYPE_WILD_VALUE |any)|) (src-mac
( MATCH_MAC_ADDR MATCH_MAC_ADDR_WILD |any| host MATCH_MAC_ADDR)|) (dest-
mac ( MATCH_MAC_ADDR MATCH_MAC_ADDR_WILD |any| host MATCH_MAC_ADDR)|)
sequence-num MATCH_SEQ_NUM
Specify a sequence number to create the
inner-match rule.
The valid range for sequence number is 1-
