106 Upgrade and Maintenance Manual RX900 S2
Expansion cards and BBU
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-12050-001.fm
For information on the population order and the capability of the slots see
"Baseboard D3144, CPUMEMR D3145, PCIR D3146 for PRIMERGY
RX900 S2 Technical Manual".
I The RX900 S2 server can be equipped with one Modular RAID controller
and two SAS RAID controllers but only for two of these RAID controllers
a BBU can be installed.
Figure 52: PCIe slot assignment
C
A
C
C
C
B
#" $
!
C
E
C
F
C
D
C
G
C
H
