Fujitsu PRIMERGY RX900 S2 - Installing the Air Guide

RX900 S2 Upgrade and Maintenance Manual 287
Baseboard
V CAUTION!
Ensure not to damage the EMI springs to comply with applicable EMC
regulations and satisfy cooling requirements and fire protection
measures.
14.6.10 Installing the air guide
Figure 183: Installing the air guide
Ê Place the air guide in the chassis (1).
Ê Fasten the captive screws (2).
/
