RX900 S2
Upgrade and Maintenance Manual
69
Power su
pply
5.4.9
Removing the power dis
tribution board
Figure 24: Removing the power distribution board
Ê
Open the cable clamps (1).
Ê
Disconnect the power cables from the baseboard (2).
Ê
Loosen the captive screws (3)
.
Ê
Remove the power distribution board from the baseboard.
/
/
0
0
1
1
2
68
70
