RX900 S2 Upgrade and Maintenance Manual 217
Processors
10.3.4 Applying the thermal paste
Figure 129: Measuring the thermal paste
Ê Remove the residual thermal paste from the processor surface.
Ê Clean the processor surface using a lint-free cloth.
Ê Use 0.2 grams of the supplied thermal paste, that is approximately one
graduation mark of the provided application syringe.
One syringe contains thermal paste for 5 processors.
V CAUTION!
Do not apply a mixture of different thermal paste types on the same
processor.
/
