RX900 S2 Upgrade and Maintenance Manual 179
Expansion cards and BBU
8.12.5 Disconnecting the BBU cable from the BBU
Figure 105: Disconnecting the BBU cable
Ê Disconnect the BBU cable from the battery.
8.12.6 Reinstalling a new BBU
Ê Perform the following two steps:
1. "Connecting the BBU cable to the BBU" on page 170
2. "Installing the BBU in the BBU holder" on page 171
3. "Connecting the BBU to the Modular RAID controller" on page 173
8.12.7 Completing the task
Ê Perform the following procedures to complete the task:
1. "Installing the rear cover" on page 48
2. "Mounting the server in the rack" on page 49
3. "Bringing the server back to operation" on page 51
4. "Closing the rack door" on page 51
