Fujitsu PRIMERGY RX900 S2 Upgrade And Maintenance Manual

178 Upgrade and Maintenance Manual RX900 S2
Expansion cards and BBU
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-12050-001.fm
8.12.4 Removing the BBU from the BBU holder
Figure 104: Removing the BBU from the BBU holder
Ê Open the cable clamps (1).
Ê Carefully press the two locking hooks (2) outward so that the BBU can be
removed from the holder at a slight angle (3).
/
0
0
/
/
/
1
