40 Upgrade and Maintenance Manual RX900 S2
Basic procedures
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-12046-001.fm
Ê Press the CSS button located on the PCI Riser (PCIR).
Ê The PRIMERGY diagnostics indicator of the faulty unit will light up.
For information on the control elements and indicators of your server see
"PRIMERGY RX900 S2 Server - Operating manual" and "Baseboard
D3144, CPUMEMR D3145, PCIR D3146 for PRIMERGY RX900 S2
Technical Manual".
Ê Take a note on the faulty component indicated by the indicator:
– Number of the component
– Faulty component
– For DIMM memory modules: Identifier of the slot
4.2 Opening the rack door
For information on how to open the front and rear doors of the rack see
"PRIMECENTER, Rack System for PRIMERGY, PRIME POWER, BS2000,
STORAGE".
Trained personnel
