Fujitsu PRIMERGY RX900 S2 Upgrade And Maintenance Manual

146 Upgrade and Maintenance Manual RX900 S2
Expansion cards and BBU
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-12050-001.fm
8.6.8 Inserting the expansion card in the slot
Figure 81: Inserting the expansion card in the slot
Ê Carefully insert the removal tool together with the expansion card in the slot
(1).
Ê Insert the slot lock (2) and relock the slot (3).
Ê Close the hot-plug slot (4).
Ê If applicable, connect the cables on the expansion card.
/
0
1
2
C
A
