RX900 S2 Upgrade and Maintenance Manual 29
Before you start
2.2 List of required tools
Before leaving for the server, please make sure that you have Phillips head
screw drivers of the size Ph0, Ph1, and Ph2 with you. You will find a list of
required tools at the beginning of each procedure.
Table 2 lists all available screws in the RX900 S2 server.
Usage Type Figure Head Tool / Bit
insert
2.5-inch
HDD/SSD
modules
M3 x 4 mm Phillips Ph0
Cable guide
screw
-- Phillips Ph0
Captive
screw/
knurled
screw
-- Phillips Ph2
Expansion
card screw
M3 x 4,5 mm Phillips Ph0
Fan cable
screw
-- Phillips Ph0
Knurled
screw
-- Phillips Ph2
Table 2: List of screws for the RX900 S2
