Fujitsu PRIMERGY RX900 S2 Upgrade And Maintenance Manual

324 Upgrade and Maintenance Manual RX900 S2
Cables
© cognitas. Gesellschft für Technik-Dokumentation mbH 2011 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-12057-001.fm
15.4.9 Removing the power distribution board
Figure 216: Removing the power distribution board
Ê Open the cable clamps (1).
Ê Disconnect the power distribution cables from the baseboard (2).
Ê Loosen the captive screws (3).
Ê Remove the power distribution board from the baseboard.
/
/
00
11
2
